Quadro Refit/Eco Surface Mounted Luminaire
QUADRO REFIT/ECO is an extended series from the Quadro family, tailor-made for refurbishment jobs for surface mounted luminaires. The innovative mounting mechanism, and special sizes facilitate fast change of luminaires from old to new, and cleverly cover the old paint mark left over by the old luminaires, i.e. there is no extra work needed for re-paint the ceiling as by using other luminaires.
It is produced by the latest aluminum profile formation technique, together with edgelit technology. Providing the possibility for size tailoring, this you do not see often in the market. With comprehensive sizes, 140-150lm/W efficiency, lumen packages, mounting versatilities, and addible features in the portfolio makes light planning task easy. It seems to be one of the best options for replacing or refurbishing old T5/T8 Louvre fixtures!
Features:
1.Fully Flush mounting
2.Up to 140-150lm/W efficiency
3.Sizes specifically for replacement purposes (cover old marks left by old luminaires)
4.Frame in one with no visible screws, elegant appearance
5.Easy for wiring, installation and maintenance (all control gears are neatly connected and pre-mounted in our factory, this facilitates simple and fast final installation)
|
Product |
Part Number |
Power（W） |
Color |
Lumen Output |
RA> |
Beam |
Dimension |
|
Quadro ECO Backlit Surface Mounted Luminaire |
SL-PAN-35W-XW-S60-D |
35W |
WW: 3000K |
4900 |
80 |
120° |
625*625*48 |
|
SL-PAN-35W-XW-S312-E |
35W |
4900 |
325*1225*48 |
||||
|
SL-PAN-40W-XW-S315-E |
40W |
6000 |
325*1525*48 |
||||
|
Quadro ECO Backlit Surface Mounted Luminaire |
SL-PAN-35W-XW-S60-D-S |
35W |
WW: 3000K |
4900 |
80 |
120° |
625*625*48 |
|
SL-PAN-35W-XW-S312-E-S |
35W |
4900 |
325*1225*48 |
||||
|
SL-PAN-40W-XW-S315-E-S |
40W |
6000 |
325*1525*48 |
|
Product |
Part Number |
Power（W） |
Color |
Lumen Output |
RA> |
Beam |
Dimension |
|
Quadro Refit Surface Mounted Luminaire |
SL-PAN-35W-XW-S60-R |
35W |
WW: 3000K |
4400 |
80 |
90° |
625*625*43 |
|
SL-PAN-40W-XW-S312-R |
40W |
5000 |
325*1250*43 |
||||
|
SL-PAN-50W-XW-S315-R |
50W |
6250 |
325*1550*43 |
||||
|
Quadro Refit Surface Mounted Luminaire |
SL-PAN-35W-XW-S60-SI |
35W |
WW: 3000K |
4400 |
80 |
90° |
625*625*43 |
|
SL-PAN-40W-XW-S312-SI |
40W |
5000 |
325*1250*43 |
||||
|
SL-PAN-50W-XW-S315-SI |
50W |
6250 |
325*1550*43 |
